Coupling - SMC-380-.3125-13mm
Coupling - SMC-380-.3125-13mm
Coupling - SMC-380-.3125-13mm
Machined coupling manufactured from 303 Stainless Steel Ends / FlexNickel Bellows with setScrew end attachments. This 1.6 Inch flexible shaft coupling has a 2.4 Inch O.D. and 0.3125 Inch and 13 Millimeter bores.
| Label | Value |
|---|---|
| Angular Misalignment | 4 deg |
| Axial Motion | 0.16 in |
| Bellows | ST-300 |
| Bore Size | 0.3125 in |
| Bore Size 2 | 0.5118 in |
| Brand | Servometer |
| Display Name | Coupling - SMC-380-.3125-13mm |
| End Attachment | Adhesive |
| End Length | 2.384 in |
| End Type | Set Screw |
| Finish | None |
| Hub | 050-33472 |
| Length | 1.6 in |
| Material | 303 Stainless Steel Ends / FlexNickel Bellows |
| Max Torque # | 4000.0000 |
| Model Number | SMC-380 |
| Outside Diameter | 2.4 in |
| Parallel Offset | 0.014 in |
| Screw Size | M5 |
| Side Thrust # | 20.6000 |
| Static Torsional Stiffness # | 8569.0000 |
| Wind Up # | 0.1700 |
| Label | Value |
|---|---|
| Angular Misalignment | 4 deg |
| Axial Motion | 4.06 mm |
| Bellows | ST-300 |
| Bore Size | 7.94 mm |
| Bore Size 2 | 13 mm |
| Brand | Servometer |
| Display Name | Coupling - SMC-380-.3125-13mm |
| End Attachment | Adhesive |
| End Length | 60.55 mm |
| End Type | Set Screw |
| Finish | None |
| Hub | 050-33472 |
| Length | 40.64 mm |
| Material | 303 Stainless Steel Ends / FlexNickel Bellows |
| Max Torque # | 4000.0000 |
| Model Number | SMC-380 |
| Outside Diameter | 60.96 mm |
| Parallel Offset | 0.36 mm |
| Screw Size | M5 |
| Side Thrust # | 20.6000 |
| Static Torsional Stiffness # | 8569.0000 |
| Wind Up # | 0.1700 |
| Quantity | Price |
|---|---|
| 1 - 9 | $239.67 |
| 10 - 24 | $219.98 |
| 25 - 49 | $201.92 |
| 50 - 99 | $185.33 |
| 100+ | $170.11 |
